ND 263适合于永久性锁固和密封螺纹紧固件。该产品在隔绝氧气的金属密封面间固化，可以防止由于震动或冲击而引起的松动或泄漏。此产品耐高温抗油脂。它能容许各种轻微表面污染，诸如切割油、润滑油、防腐蚀剂和保护液所含的油污等

产品详情

ND263——耐高温、耐油、高强度螺纹锁固密封胶

典型应用：

ND 263特别适合重载应用，如发动机箱螺栓、泵壳螺栓以及其他大强度紧固件的装配。ND 263固化性能很好，不仅在作用于活性金属（诸如黄铜、紫铜），同时作用于惰性基材，诸如不锈钢和镀层表面。

技术特征：

化学类型：甲基丙烯酸酯

颜色：红色

初固速度： 10-25分钟

粘度： 400-600cps

保质期（25℃）： 24个月（未开封）

工作温度： -51℃至180℃

固化性能：

完全固化时间： 24小时

典型破坏强度： 16.8-34.8 N•m

典型拆卸强度： 19.2-39.6 N•m

该产品性能同LOCTITE263产品.

Vibra-Tite Part #	Available Sizes	Competes with Loctite® #	Approx. Viscosity	Max Gap Fill (IN)	Torque Break / Prevail	Temp	Fixture	Specific Gravity	Primer	Specs Met
			(cP)		(in LB)	Range °F	Time
111		222	Low Strength - Removable - Purple
11102	2 mL Bullet		900-1500 Thixotropic	0.007	75/25	-65 to 300	15-20min	1.05	N, T	MIL-S-46163A ASTM D-5363 NSF Non-Food
11110	10 mL Bottle	21463
11150	50 mL Bottle	21464
11125	250 mL Bottle
11100	1 L Jug
11199	100 pc Fishbowl
121		242	Medium Strength - Removable - Blue
12102	2 mL Bullet		900-1500 Thixotropic	0.007	100/45	-65 to 300	10-20min	1.06	N, T	MIL-S-46163A ASTM D-5363 NSF Non-Food
12110	10 mL Bottle	24221
12150	50 mL Bottle	24231
12125	250 mL Bottle	24241
12100	1 L Jug	24243
12199	100 pc Fishbowl
122		243	Oil Tolerant - Removable - Blue
12202	2 mL Bullet		1300-3000 Thixotropic	0.015	195/70	-65 to 300	20-30min	1.1	N, T
12210	10 mL Bottle	24077
12250	50 mL Bottle	24078
12225	250 mL Bottle	24079
12200	1 L Jug	21433
12299	100 pc Fishbowl
123		246	Medium Strength High Temp - Blue
12350	50 mL Bottle	29514	2600			-65 to 450	5min	1.15		ASTM D-5363
125			Medium Strength Gel - Removable - Blue
12508	8 mL Tube		Gel	0.015	120/45	-65 to 300	20-30min	1.1	N, T
12508BC	8 mL Tube
12535	35 mL Pump
131		262	Permanent Strength - Red
13102	2 mL Bullet		1300-2300 Thixotropic	0.007	200/250	-65 to 300	15-20min	1.1	N, T	MIL-S-46163A ASTM D-5363 NSF Non-Food
13110	10 mL Bottle	26221
13150	50 mL Bottle	26231
13125	250 mL Bottle	26241
13100	1 L Jug	26243
13199	100 pc Fishbowl
132		263	High Strength Primerless - Red
13250	50 mL Bottle	1330585	400-600	0.007	275 / 290	-65 to 360	5min	1.1		ASTM D-5363
135			Permanent Strength Gel - Red
13508	8 mL Tube		Gel	0.015	200/100	-65 to 300	20-25min	1.1	N, T
13508BC	8 mL Tube
13535	35 mL Pump
13525	250 mL Tube
137		272	High Temp/High Strength - Red
13750	50 mL Bottle	27240	4000-12000	0.007	300/200	-65 to 400	20-30min	1.1	N, T
13725	250 mL Bottle	27270
13700	1 L Jug	27285
140		271	High Strength - Red
14002	2 mL Bullet		400-600	0.007	250/250	-65 to 300	10-15min	1.1	N, T	MIL-S-46163A ASTM D-5363
14010	10 mL Bottle	27121
14050	50 mL Bottle	27131
14025	250 mL Bottle	27141
14000	1 L Jug	27143
14099	100 pc Fishbowl
146		277	Large Diameter/High Strength - Red
14602	2 mL Bullet		6000-8000	0.01	250/250	-65 to 300	30-40min	1.1	N, T	MIL-S-46163A ASTM D-5363
14610	10 mL Bottle	21434
14650	50 mL Bottle	27731
14625	250 mL Bottle	27741
14600	1 L Jug	27743
150		290	Medium Strength - Wicking Grade - Green
15002	2 mL Bullet		20-55	0.004	85/200	-65 to 300	10-15min	1.1	N, T	MIL-S-46163A ASTM D-5363 NSF Non-Food
15010	10 mL Bottle	29021
15050	50 mL Bottle	29031
15025	250 mL Bottle	29041
15000	1 L Jug	29043
325		425	Plastic Parts - Blue
32520	20 gm Bottle	42540	80	0.004	4/2	-65 to 180	2min	1.1
